EQ Microinverter 1T1
The EQ Microinverter 1T1 is a single-module, module-level PV inverter for residential and small commercial rooftops where per-panel conversion helps manage shading, orientation spread, and complex layouts.
AC power is produced at the module, which can simplify homerun planning versus high-voltage DC strings — subject to project design, gateway/monitoring pairing, and grid rules in your market. Use the published electrical limits in the table below together with installation PDFs on Support and checklists on Install.
Who it fits: installer and EPC teams specifying microinverter architectures for EU-style low-voltage AC branch circuits, with monitoring via PLC through the compatible EQ Gateway (see datasheet).
Built for real rooftops — module-level PV conversion
Energy harvest
MPPT voltage range and start-up behaviour are defined in the published datasheet (see technical table). Pair modules within those limits and validate clipping vs. irradiance for each project.
Compact hardware
1.48 kg unit weight and up to 16 A max input current (per datasheet) suit many high-power modules — always confirm DC current and Voc against the module STC table and site temperature.
Integration
PLC to the EQ Gateway for monitoring (per system design). Built-in relay architecture is documented in the install manual — follow local disconnect and rapid-shutdown rules for your jurisdiction.
Outdoor durability
IP67 enclosure rating for outdoor mounting. Operating temperature and derating curves are defined in manufacturer documentation — use them for thermal modelling on your site.
Industrial-Grade PLC Connectivity.
Simplified System Architecture.
PLC-based monitoring to the gateway supports commissioning and O&M workflows on multi-unit sites — network performance depends on site topology; refer to the networking guidelines in your project package.
Technical Specifications
Representative datasheet extract — confirm revision with your RACOFORCE order acknowledgement
| Category | Parameter | Value |
|---|---|---|
| Input (DC) | Recommended Module Power | 400W - 700W+ |
| Max. Input Voltage | 60 V | |
| Start-up Voltage | 22 V | |
| MPPT Voltage Range | 12 V - 55 V | |
| Max. Input CurrentKEY SPEC | 16 A (Supports 182/210mm cells) | |
| Max. Short Circuit Current | 25 A | |
| Output (AC) | Peak Output Power | 550 VA |
| Rated Output Power | 500 W | |
| Rated Output Current | 2.17 A | |
| Nominal Voltage | 230 V (Range: 184-276 V) | |
| Nominal Frequency | 50 Hz / 60 Hz | |
| Power Factor | > 0.99 (Adjustable 0.8 leading...0.8 lagging) | |
| Efficiency | Peak Efficiency | 98.0% |
| MPPT Efficiency | 99.9% | |
| Night Power Consumption | < 20 mW | |
| Mechanical | Dimensions (W × H × D) | 215 × 173 × 31 mm |
| WeightKEY SPEC | 1.48 kg | |
| Protection Class | IP67 (NEMA 6) | |
| Cooling | Natural Convection (No Fans) | |
| Features | Communication | PLC (Requires EQ Gateway) |
| Warranty | 25 Years | |
| Compliance | Grid Standards | EN 50549-1, VDE-AR-N 4105, CEI 0-21 |
| Safety Standards | IEC/EN 62109-1, IEC/EN 62109-2 |
WEATHER TESTED,
DURABILITY ENSURED
Product warranty duration and conditions are stated in the official warranty document supplied with your purchase — retain it for end-customer handover and service claims.
